| قابل للتركيب على | Wiring the BMS:
1. Connect the B- Cable:
- Begin by connecting the B- cable of the BMS to the total negative pole of the battery pack.
2. Cell Wiring:
- Start from the thin black cable connected to B-.
- The second wire connects to the positive terminal of the first battery cell.
- Continue connecting each cell’s positive terminal in sequence.
- Finally, insert the B+ cable into the BMS and connect it to the positive terminal of the last cell.
3. Verify the Setup:
- After completing the wiring, check if the green indicator light is on.
- Use the Bluetooth app or PC software to check for any fault alarms.
- Measure the voltages at B+ and B-. They should match the voltages of P+ and P-. If the voltages match, the BMS is functioning properly. If not, recheck and rewire according to the steps above.
Removing the BMS:
1. Turn Off the Load Power:
- Turn off the load power switch to prevent any electrical issues during disconnection.
2. Disconnect the Cables:
- If there are two cables, start by pulling out the high-voltage cable first, followed by the low-voltage cable.
- Then remove the P- cable from the BMS.
3. Final Removal of B- Cable:
- Finally, disconnect the power line B- to complete the BMS removal process. |
