نظرة عامةFinosel® offers standard simplex and duplex patch cords in a variety of
connectors & cables configurations. patch cords are available with full
standard optical specifications, precise length tolerances. All assemblies
are 100% inspected for optical characteristics and fiber end face finish.
Available with zip cord or simplex OM1, OM2, OM3, OM4 and OS2 patch
cables. We offer LC, SC, ST, MTRJ, or any special Connectors. All patch cords
are factory polished and 100% optically tested for superior performance.
Features & Benefits
• High quality zirconia ferrules.
• Good repeatability and interchange.
• Standard connectors LC, SC, ST, FC, LSH, MTRJ, MU are available.
• Single mode (OS2) and multimode (OM1, OM2, OM3, OM4) are available.
Applications
• Data Center, Enterprise.
• Fiber to the X (FTTX/FTTH).
• LAN, WAN, CATV and Telecommunications Network.
Standards
• RoHS, ISO9001Compliant.
• IEC 61754, IEC 60793-2-10, IEC61300-3-35.
• TIA 604 (FOCIS), TIA/EIA 492AAAE, TIA/EIA-568-B.3 and Telcordia.
Performance
Cable Retention: > 25 pounds.
Mating Durability: < 0.25 dB increase after 500 mattings.
Thermal Cycling Performance: Δ dB < 0.20 dB (-40°C to +80°C, 40 cycles).
Includes Accessories
MT-RJ and LC Patch Cords.
SC and ST-style Patch Cords.
Graded-Index Multimode Fiber.
Typical SM mated pair return loss: <-55 dB.
Operating temperature range: -40°C to +80°C.
Typical mated pair insertion loss - Multimode: <-55 dB.
Mated Pair MM Insertion Loss: < 0.60 dB (0.25 dB Typical).
Fiber Specifications: Single mode, 62.5/125 μm or 50/125 μm.
