Hobi Mechatronics 128X64 0.96 Inch I2C OLED Graphic LCD Screen 4 Pin(Blue)

It is an OLED screen with 128x64 bit screen resolution. User interfaces can be easily created with this 0.96 inch screen. Arduino, raspberry pi, STM32 etc. Suitable for working with development boards.

You can use this approximately 1' sized graphic OLED screen in your Arduino and other microcontroller projects. Thanks to its use of OLED technology, you can obtain high-contrast images without the need for backlight.

The module comes with SSD1306 driver integrated. You can easily connect SPI or I2C interfaces. Thanks to the regulator on it, it works smoothly at 3V or 5V voltages. You can use more than one module at the same time by changing the I2C address with the solder jumpers on the card. It draws an average current of around 20 mA.

You can easily use the 0.96' I2C OLED screen in your Arduino and other microcontroller projects, thanks to its low energy consumption, thinness and lightness. The graphic color of this screen is blue and yellow. This 128x64 resolution screen uses less pins in your projects because it uses the I2C protocol. There are 4 pins on the I2C OLED screen.

You can easily develop your Arduino projects with U8GLIB. It also supports Adafruit libraries.

Driver Chip: SSD1306

Model: 128x64 Oled Screen

Interface Type: IIC/I2C

Working Voltage: 3.3-5V

Resolution: 128x64

Screen Size: 0.96inch

Color :Blue

Background:Black

Drive Chip:SSD1306

Communication Interface:I2C(IIC)

Pin Sequence:Gnd-Vcc-Scl-Sda

It has very low energy consumption

Visible Angle: >160°

Operating Temperature: -40 ? to 70 ?

Size:27.5x28.5mm

Package Included

1 Piece 128x64 0.96 Inch I2C Oled Graphic LCD Screen 4 Pin
