Waterproof 3660 Brushless Motor 3100KV with 80A Brushless ESC Programming Card Replacement for TRAX4 WLtoys Remote Control Car 1/8/1/10 Tamiya

نظرة عامةFeatures: 4 Pole 12 Slot Hi-torque Motor Design. Stator - Super Thin (0.35mm) Laminations. High Quality: CNC Machined 6061 T6 Billet Aluminum Heatsink Can, High Purity Copper Windings. Maximizes Efficiency, High RPM ABEC5 Oversized Bearings. Precision balanced rotor, smoothness for best reliability and maximum RPM. The package includes 3100KV brushless motor, 80A brushless ESC and programming card, Replacement for TRAX4 WLtoys Remote Control Car 1/8/1/10 Tamiya. Specifications: KV(RPM/Volt): 3100KV Watt: 1200 Max RPM: 50000 Max Voltage: <12V Max Amps: 100A Rotor Poles: 4 Diameter: 35.5mm Length: 59mm Shaft Length: 17mm Connector: 4.0mm Gold Weight: 218g Shaft(mm): 3.175mm 80A  Brushless ESC: Name: 80A ESC Cont.Current/Burst Current: 80A/480A Motor Type: Sensorless Brushless Motor For 2S Lipo or 6 Cells NiMH: 1. On-road: 3670/3660-Size or smaller motor with the KV<3000KV 2. Off-road: 3670-size or smaller motor with the <3000KV For 3S-4S Lipo or 9 cells NiMH: On-road: 3660-Size or smaller motor with the KV<3000KV Off-road: 3660-size or smaller motor with the <3000KV Suitable Car:  1/10 1/8 Remote Control Car Resistance: 0.0005ohm Battery: 2-4S Lipo/4-12Cells NiMH BEC Output: 6V/5A (Switch mode) Dimensions/Weight: 52*39*38mm/92g Programming Card: Low Voltage Cut off: 3.1V/Cell 2.8V/Cell 3.3V/Cell No Cut-off Start Mode: Medium, Soft, Strong Max Brake Force: 25%, 50%, 75%, 100% Max Reverse Force: 25%, 50%, 75%, 100% Neutral Range: 6%, 9%, 12%, Work State Package Information: Package Size: 12*8*5cm Package Weight: 362g Package List: 1* 3100KV Brushless Motor 1* 80A Brushless ESC 1* Programming Card
