Notice:
1. Before turning on the Gimbal, the mobile phone must be placed in the middle (turning on the HQ3 without the mobile phone or without a phone in centering will cause abnormal vibration or shaking).
2. Please use the USB cable configured by us to charge them, or use the cable which USB-A cable at one end and the TYPE-C at the other end. However, cables with TYPE-C at both ends cannot be used. Cables with TYPE-C at both ends cannot be used.
3. The Gimbal has a limited angle. When is manipulated to move to the limited angle position, the head will automatically turn on the self-protection to protect the internal current (usually manifested as no matter how to manipulate the joystick, the head will not turn), first of all, this is the normal machine self-protection phenomenon. Usually occurs in the following situation: the gimbal tilted forward 30 degrees and the phone lens up or down to the angle of 30 degrees. When this happens, you can restore the mobile state in the following way: take HQ3 right, let HQ3 not be in the tilt state, and then shake the phone slightly with your hand.
4. does not support APP. Only Bluetooth-compatible!
Product Specifications:
Model: SK062
Product Material: Environmental Protection ABS Glass Fiber
Charging Method: 5V1A
Battery Capacity: 2200mAh
Product Load: 260g
Support Phone Width: 55-85mm
Endurance Time: Laboratory stationary placement test results are 9 hours
Product Weight:295g(battery included)
Name of Bluetooth Device: SK062
Suitable phone size and weight for HQ3:
Thickness less than 8.2mm.
The load should be less than 260g.
Packing list:
SK062 Gimbal Stabilizer*1, Tripod*1, Data cable*1, Instruction manual*1
