Technical specifications
Projected beams 2V 1H 1D
Working range 30 m
Levelling accuracy - horizontal beam ±1 mm at 7 m
Levelling accuracy - vertical beam ±1 mm at 7 m
Self-leveling time ≤5 s
Self-leveling range ±3°
Laser class II
Laser type 525 Nm
Battery type 3,7 V; Li-Ion
Thread for tripod 5/8"
Operating temperature range -10 ... +40 °C
Storage temperature range -20 ... +55 °C
Weight : 1,04 kg
* V - vertical plane, H - horizontal plane, D - plumbing point
