DALY Smart Home Storage BMS 100A 200A 8S 16S UART & CAN/RS485 Protection Board for LFP Lithium Battery Pack(Include 3,2''screen and bluetooth module)

Overview1.Sepecification Structure: Split Type: R16L Series Range: 8S /16S Battery Type: LiFePO4 Application: Home Energy Storage, Communication Stations,Building Energy Storage,industrial Equipment Backup Power, etc. Parallel current limiting: 5A Rated Current: 100A/200A CommunicationFunction: UART / RS485 / CAN Software Features: APP / PC / IOT Advantageous Features: Software auto coding |150mA passive balance |Any parallel connection |Inverter Communication Cable Specifications: 24AWG NTC Length: 28AWG 250mm 2. Product Dimensions Mainboard: 300*100*29mm Interface Board: 155*30*18mm 3. How to select the Smart Home Storage BMS for your battery pack ? A. Battery Type Compatibility: LFP/NCM/ LTO. (If using LiFePO4 batteries, ensure the BMS is compatible with 3.2V nominal per cell.) B. Number of Cells in Series (S) ：For example, for a 8S battery pack (four cells in series), the BMS must select the 8S. C.  Current Rating (Discharge and Charge Current)：For example, if your battery can discharge at 60A, your BMS must support at least 60A continuous discharge. Also you can add a margin (e.g., 20–30%) for safety. D. Balancing Functionality: Passive Balancing: Dissipates excess energy as heat OR Active Balancing: Transfers energy between cells. E: Communication Protocols: Supported Protocols: CANbus, RS485, UART, or Bluetooth. Ensure the BMS supports the protocol your inverter or smart home system uses. Packing List: Smart Home Storage BMS *1 3.2'' LCD Display *1 Bluetooth Module *1 Interface board *1 Sampling cable *1 CAN/RS485 cable *1 B+ connecting wire *1 Interface board Cable *2 NTC *1 Key switch *2 Users Manual *1
